• Voltage display of main and video battery
• Voltage range: 6 – 30V
• Current display up to 70A, soon available up to 140A with a different current sensor.
• Up to 50'000 mAh battery usage display
• GPS altitude
• GPS ground speed
• GPS coordinates
• GPS number of satellites
• GPS heading
• GPS variometer
• Ground distance to home
• Line of sight distance to home
• Elevation
• Artificial horizon
• Date
• Temperature
• Elapsed time
• Call sign
• RSSI display and inputs analog or digital
• Five servo inputs for connection to regular RC receivers, also supports combined PPM inputs for two separated receivers, is possible to display RSSI for each one
• Dual receiver inputs, RVOSD switch to second receiver if main receiver had lost R/C signal

Autopilot Features:

• G-force display up to 8G
• Flight summary display of Altitude, speed, range, distance traveled, current and G-force
• Six display modes. Advanced, simple, radar, Raw sensor inputs, GPS signal and no OSD screen
• Display GPS satellites in view signal level and position
• User can configure the OSD display width
• Metric/imperial units selection
• Configuration of all OSD parameters via infrared control, physical access to the OSD board not needed for configuration, no computer required
• Configuration of in-flight menu items via RC transmitter, only one extra auxiliary channel required for accessing all OSD-autopilot options
• On screen display items can be enabled-disabled or moved to different positions
• Range warning
• Voltage warning
• Battery capacity warning
• Lost signal warning
• RSSI level warning
• Elevation warning
• GPS fail warning
• Autopilot modes, Return home, Level flight, Heading hold, Position hold, Fly by wire and waypoint navigation.
• Is possible to set up to 15 3D waypoints via remote control
• Programmable virtual fence to keep airplane at safe distance on waypoint navigation mode
• Automatic return home if virtual fence distance exceeded, RC signal lost or latest waypoint reached
• Automatic selection of PAL NTSC
• Buffered video input and output processing, plug and play with all FPV cameras
• Integrated GPS backup battery
• Integrated temperature sensor, external temperature sensor optional
• Current draw 85mA@12V
• Provides filtered voltage 5V or 12V for both camera and video transmitter
• Automatic selection of voltage input from higher voltage battery
• Adjust of most autopilot features via configuration wizard
• Dual level throttle management on autopilot mode for optimum battery usage
• Upgradeable firmware
• Home setting automatically
• Detects R/C link lost by glitch counter or failsafe level
• Detection of failsafe on the throttle channel configurable for over or under normal throttle range
• Display estimated maximum range left
• Board position can be configured by software to be rolled 0-90-180-270°, front-rear can be reversed also
• Neutral attitude adjustable via software
• Attitude input from integrated IMU
• Attitude input from external IR sensors (optional)
• Turn and climb rate display
• G-force display
• Adjustable artificial horizon size and position
• Autopilot controls four servo output channels for regular airplanes with elevator, aileron, throttle and rudder. Supports differential ailerons airplanes and flying wings with elevons
• Barometric altitude, variometer, pressure
• All parameters on the screen redraw at 50-60Hz, high refresh rate for smooth relaxing display
